Lg AGB34327803 Steam Nozzle Assembly (Dryer) OEM Part

Product Details

Genuine Lg part. See all items in Dryer Nozzle.

Cross Reference Information

Part Number AGB34327803 replaces AP5975416, AGB34327801, 3284285, PS11708532.

Description

This steam nozzle assembly directs a fine spray into the dryer drum during Steam/Refresh cycles. Replacing a clogged or cracked nozzle helps restore proper mist distribution and reduces leaks or drips from the nozzle area.

• Channels water from the inlet line into the drum for steam-enabled cycles
• Maintains the correct spray pattern and coverage
• Common symptoms: no mist/steam, weak or uneven spray, dripping, mineral buildup, or leaks around the nozzle
• Can contribute to wet spots if the spray is misdirected or blocked

What's included: 1 steam nozzle assembly Install notes:

• Unplug the dryer and turn off the water supply before servicing
• Allow the appliance to cool; wear gloves and eye protection
• Access is typically near the front bulkhead/drum opening; remove panels as required per model
• Ensure hose seating and clamps are secure; test for leaks after installation
