Product Details
Genuine Mtd part.
See all items in Log Splitter Bearing.
Cross Reference Information
Part Number 935-0149 replaces AP6145458, 1620622, 1738433, 581615, 735-0149, 741-04006, 751-3008, GW-1738433, GW-B1738433, IH-109020-C1, PS9163788.
Description
This bushing, also known as a plain bushing, plain bearing, or sleeve bearing, is used in lawn and garden equipment to prevent excess friction between two items that slide against each other. The bushing is used to secure the flange bearing on lawn mowers and other equipment. Bushings are also located on the wheels of lawn mowers. Sometimes, the bushings can get worn out or become damaged through normal use. When this occurs, the part will need to be replaced.If the wheel bushing needs to be replaced, the equipment should be raised and placed on a stable surface. The cap on the wheels can be removed using a screwdriver. Find the clip on the axle and remove it using a flat head screwdriver and a hammer. The wheel can then be removed and the wheel bushing can be taken out of them. Insert the new part into the center wheel hole and secure using a hammer.This gas line bushing is a genuine OEM replacement part directly sourced from the manufacturer. It comes as an individual part. This bushing is made to fit lawn tractors, generators, tillers, snowblowers, log splitters, and lawn mowers manufactured by Craftsman, Murray, Yard-Man, MasterCut MTD, Troy-Bilt, and Cub Cadet.
