Mtd 725-04434 Wire Harness Assembly OEM Part

Product Details

Genuine Mtd part.

Cross Reference Information

Part Number 725-04434 replaces AP6066314, 1826649, PS10004639.

Description

This wire harness assembly is an authentic OEM replacement part sourced directly from the manufacturer. It is the grouping of wires and electrical cables needed to power the lawnmower and other lawn and garden equipment. The harness holds all the wiring together in one area. If this assembly becomes damaged due to debris from the lawnmower or even being chewed through by animals while the machine is stored, it will have to be replaced in order for the machine to run.This project requires a screwdriver, socket set, pliers, and wire cutters and strippers. This will take between one and two hours, depending on your skill level. Remove the fender to get access to the harness. Remove the battery and disconnect all electrical connections on the machine. Next, remove the harness and install the new one. Reconnect all wires making sure to follow the process exactly so that the connections are correct. Reinstall the battery and fender. Check all components of the machine to make sure the connections are right.This wire harness assembly is sold individually. It is designed for use in lawnmowers and other small engines manufactured by Troy-Bilt and MTD.
