Mtd 783-08690A-0637 Belt Keeper OEM Part

Product Details

Genuine Mtd part.

Cross Reference Information

Part Number 783-08690A-0637 replaces AP6810445, 783-08690-0637, 783-08540, 783-08540-0637, 783-08690.

Description

This belt keeper is a genuine OEM part that is sourced directly from the manufacturer for use on lawn mowers and lawn tractors to stabilize the deck belt and prevent excessive friction on the belt. If the belt keeper is damaged or missing, the belt may slip off the mower and cause the mower to stop cutting. Regular inspection of the belts will reveal any damage to the belt keeper that needs addressing. If the belt keeper is missing, screws will need to be purchased separately. Practice safe working practices when repairing the lawnmower. Remove the key and disconnect the spark plug. Wear safety gloves. Park the mower on a flat surface and lower the deck to the lowest position. Locate the deck belt guards and remove them from the mower. Remove the screws securing the belt keeper and take the damaged belt keeper off. Install the new belt keeper and use the screws from the original belt keeper to secure it to the mower. Reinstall the belt guards. Reconnect the spark plug. This belt keeper is a black metal part that is sold as an individual unit. It does not come with hardware. It is designed for use on lawn mowers and lawn tractors manufactured by MTD, Troy-Bilt, Yard Machines, Cub Cadet, and Yard-Man.
