Mtd 753-06303 Ignition Coil OEM Part

Product Details

Genuine Mtd part. See all items in String Trimmer Ignition Controls.

Cross Reference Information

Part Number 753-06303 replaces AP6093676, 1831777, PS9119312.

Description

The ignition coil replacement module assembly is used in lawn trimmers. It creates charges of high pulses of electric current. The ignition coil's current sends the voltages down the spark plug wire to the spark plug and then the engine. Signs the ignition coil may need replacing include poor performance, inability to engage the machine, and unusual noises. An ignition coil will wear out with routine use, or it can become damaged with improper usage. Replacing the ignition coil in a trimmer requires a screwdriver, socket set, adjustable wrench, and star bit screwdriver. Allow the engine to cool completely before disassembly. It can be achieved in about 30 minutes. Wear gloves for safety. Make notations of all removed pieces for easier reassembly after the replacement part has been installed.This replacement module is an authentic OEM part sourced from the manufacturer. It is compatible with several different lawn equipment brands, including MTD, Cub Cadet, and Troy-Built. The module is found in numerous trimmer machines. The replacement part is sold individually as one module assembly. Included with the assembly are the screws, spark plug boot, and rubber insulated wire. The piece is made from durable plastic and metal.
