David W Hornersville , MO October 07, 2024 Appliance: Model THERMADOR CMT 19 Thermador cmt 19 oven bake element out I ordered the part that came up on the search, it wasn't exact because my oven was a made in 1981 but the replacement part was very close to the original. The difference was that the original mounting plates that attach the element to the back wall of the oven were circular disks with 3 holes around it and the replacement mounting plates were rectangular in shape with a single hole at the top. I turned off the breaker that provided electricity to the oven and removed the 3 screws from the mounting plates. I carefully slid the element toward me and pulled the wire off each side of the element. Then set the new element in place, pushed the power wires back on each side of the element, and carefully guided the wires and ends of the element through the holes in the back wall of the oven until the small mounting plates were flush with the oven wall. This is where I had to modify the installation slightly in my case because the original part with 3 mounting holes per side was not available anymore. I took a drill and small drill bit, put the bit through the single hole in each mounting plate and drilled carefully through the oven back wall. Next, I inserted a single screw (left over from the original installation) through each mounting plate. It held perfectly without problem and the new mounting plates were even large enough to cover the small holes where the 3 original screws were. I turned the breaker back on, turned the oven on and burned the "new" off the element by bringing it up to about 450 degrees. We cooked a pizza in it later in the day and it worked great! A small flashlight or headlight works wonders during your work. The original phillips head screws were tight but not impossible to remove. As I said, in my case I had to make a small modification that required a drill and small drill bit. I was very happy to give new life to a classic well-made appliance. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Robert S Joliet , IL January 06, 2020 Appliance: Model THERMIDOR Oven element burned out Ordered replacement element but screw holes were in different location on element. This is a double oven with the same element for both but could only find the 1 hole, not 3 hole. Had to remove old, measure holes and refill holes. Hardened stainless plate? More work than expected but worked out ok. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
