Admiral Dryer LDEA100BCE Noisy

Get your dryer spinning smoothly again - install the Whirlpool 341241 OEM Drum Belt in minutes.

Why this belt?

• Exact factory spec: 92 ¼-inch length × ¼-inch width, 4 ribs / 3 grooves - built to Whirlpool standards, not a generic copy.
• Broad compatibility: Fits most Whirlpool-made dryers - Kenmore 110-series, Roper, Estate, Maytag, KitchenAid, Admiral, Crosley, Amana & more.
• Quiet, durable rubber: Reinforced EPDM resists cracking and stretch for years of reliable tumbling.

Fixes these common dryer problems

DIY install — about 15 minutes

1. Unplug dryer; remove lint screen housing & front panel.
2. Release belt tension at idler pulley; lift drum slightly to slide old belt off.
3. Loop new belt around drum, idler pulley and motor pulley (ribbed side down).
4. Re-assemble, run test cycle - enjoy quiet, consistent tumbling.

Made for most Admiral, Crosley, Norge, and Magic Chef dryers. Kit includes 2 drum support rollers, 2 support shafts, 4 screws, 2 spacers, 2 washers, 2 retaining rings and instruction sheet.

The Clamp is an OEM part for Whirlpool dryers. This clamp ensures tight and secure connections within the dryer, particularly in securing ducts and vents that are essential for proper airflow and operation.

Clamps may need replacement due to loss of tension, corrosion, or damage from regular use. A compromised clamp can lead to operational issues such as prolonged drying times or excessive noise, resulting from loose parts or improper ventilation.

Symptoms of a bad Clamp include:

• Loose or detached vents or hoses, leading to inefficient dryer operation.
• Increased drying times, as a result of compromised airflow from unsecured ducts.
• Unusual vibrations or noise, indicating that internal components may not be securely fastened.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This dryer exhaust fan is used on many Admiral, Crosley, Hoover, Magic Chef, Maytag, Montgomery Ward and Norge brands. Size: 3-1/8 inches deep, 8 inch fin diameter, 7-1/8 inch hub diameter, 20 standard fins, 1/2 inch diameter motor shaft, 7/16 inch motor shaft diameter to flat side of shaft. Blower wheel clamp not included. For the clamp order WP312967.

Kit contains 2 pads, 1 right glide, 1 left glide, and instruction sheet. Support brace no longer included.

Can use 410233

Right hand side. Used most Admiral, Crosley, Norge, and Magic Chef dryers. Includes glide and felt pad.

(Adhesive Sold Separately).To order adhesive use part number WPY055980.This Part Can Be Used As Both The Front And Rear Seal In Some Models

This replacement idler pulley keeps the drive belt tight and tracking correctly so the drum can rotate smoothly. It restores quiet, consistent operation when the original pulley is worn or seized and causing belt slippage or noise.

• Maintains proper tension on the drive belt to enable smooth drum rotation
• Provides a low-friction surface for the belt to ride on and stay aligned
• Common symptoms of failure: squealing/chirping, belt fraying or coming off, burning rubber smell, or a drum that won't turn
• Replace if the pulley wobbles, binds, or the rim/bearing is worn

• Disconnect power; if gas, shut off the gas supply
• Note belt routing, relieve tension from the idler arm, and remove the belt from the motor pulley
• Remove the retaining hardware from the old pulley, install the new pulley on the idler arm shaft, and re-tension the belt
• Manually rotate the drum to verify smooth belt tracking before reassembly and test run

This is the drive motor that powers your washer's drive system. It turns the basket for wash and spin, restoring smooth, reliable operation when the original motor is weak, noisy, or fails to start. What it does and common symptoms:

• Provides the torque needed to rotate the basket during wash and spin cycles
• Symptoms of a failing motor include: no agitate, no spin, or cycle stalling
• Can trigger motor/drive-related error indications on some models

• 1 drive motor

• Disconnect power and turn off water supply before servicing
• Access the motor per your model's service procedure; label and transfer connectors one at a time
• Ensure the drive system turns freely by hand; correct any binding in related components before powering on
• After installation, run a diagnostic or spin test to verify operation

This idler assembly is the spring-loaded belt tensioner that keeps the drive belt correctly tightened. Replacing a worn or seized idler restores smooth belt tracking, reduces squeal, and helps prevent slippage or loss of drive.

• Maintains proper tension on the drive belt for reliable power transfer
• Helps prevent belt slippage, squealing, or the belt coming off the pulleys
• Supports smooth rotation of the driven components
• Failure symptoms can include noise from the belt path, a frayed or derailed belt, or loss of motion

• Disconnect power and allow all moving parts to stop before servicing
• Access the belt path; relieve belt tension and remove the old idler assembly
• Install the new assembly; ensure the pulley spins freely and the belt is centered in the groove
• Manually rotate the system to verify alignment and clearances before restoring power

Left hand side.

Right hand side. For the drum glide and felt pad order LA-1006.

This rear support assembly stabilizes the appliance's rear housing and helps keep internal components aligned for smooth operation and reduced vibration. It restores proper rear-end support to prevent rubbing, noise, and uneven motion. What it does:

• Provides a stable mounting point for the appliance's rear section to maintain alignment
• Reduces vibration and rattling caused by a loose or worn rear support
• Helps prevent rubbing, scraping, or grinding noises from misaligned components
• Restores proper fit between the rear housing and moving parts to promote smooth operation

• One rear support assembly

• Disconnect power (and gas if applicable) before beginning any repair
• Access typically requires removing the appliance's rear panel or cabinet; follow OEM service manual steps
• Inspect surrounding mounting hardware and replace any worn fasteners for a secure fit

Felt pad.
