Frigidaire Range FFEF3020LBB Element will not heat

The Large Surface Element Switch is an OEM replacement part for Frigidaire ranges and cooktops. It is a component that controls the power and temperature settings for one of the larger surface heating elements on the appliance.

Symptoms of a faulty Large Surface Element Switch include:

• Difficulty in adjusting or maintaining consistent heat settings
• The surface element not heating up or cycling on and off unexpectedly
• Flickering or erratic behavior of the surface element
• Burning smell or visible signs of overheating

Causes of a bad large surface element switch can include normal wear and tear, exposure to excessive heat or moisture, or electrical malfunctions.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore range and cooktop models.

The Surface Element is an OEM part for Frigidaire ranges. The small surface element is responsible for providing direct heat to the cookware placed on the corresponding burner of the electric cooktop or range. This element is typically located underneath the glass surface of the cooktop or range, ensuring efficient and even heat distribution for cooking.

Symptoms of a failing Surface Element include:

• The element not heating up at all
• Heating unevenly or only partially
• Noticeable damage or blistering on the element itself
• The control switch not regulating the temperature properly

Causes of a bad surface element can include a burnt-out coil, a break in the element's continuity, or problems with the connection points such as corrosion or loosening. Regular wear and tear from cooking can also lead to degradation over time.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Small Surface Element Switch is an OEM replacement part for Frigidaire electric ranges. It serves as the control knob and circuitry to safely power one of the smaller cooking elements.

Symptoms of a bad surface element switch include:

• Inability to ignite or regulate heating for its assigned zone
• Switch knob that feels loose, won't click smoothly, or won't stay set
• Intermittent or unreliable power to the smaller element coils
• Tripped circuit breakers upon use that don't reset

Causes relate to thousands of rotations wearing micro-switches and wiring terminals within the control assembly. Regular cleaning around knobs can prevent accelerated deterioration from baked-on debris conducting excess heat.

This genuine OEM replacement part is compatible with other brands including Electrolux and Kenmore as well.

The Surface Element is an OEM part for Frigidaire electric ranges. It is the heating element located on the cooktop, responsible for providing the heat necessary for cooking. This component is essential for the proper functioning of your stove, ensuring consistent and reliable heating for various cooking tasks.

Causes of a bad surface element can include wear and tear from regular use, damage due to spills or overheating, or electrical failures such as a short circuit. A faulty surface element can result in uneven cooking or complete failure to heat.

Symptoms of a bad surface element include:

• Element not heating up
• Uneven heating or hot spots on the element
• Visible damage such as burns or cracks
• Element cycling on and off erratically

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Surface Element Control Switch is an OEM part for Frigidaire electric ranges and cooktops. It is a critical component that controls the operation of the surface heating elements, allowing you to turn them on and off, and select the desired heat settings.

Symptoms of a faulty Surface Element Control Switch include:

• Inability to turn on or control the surface heating elements
• Inconsistent or erratic heat output from the elements
• Elements not cycling on and off properly or staying on continuously
• Heating elements not responding to temperature adjustments

Causes of a bad Surface Element Control Switch can include electrical faults, physical damage, or wear and tear over time due to frequent use and exposure to high temperatures.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Broil Element is an OEM part for Frigidaire ovens. This element provides the intense heat necessary for broiling, ensuring that food is cooked evenly and thoroughly from above. It's essential for tasks such as broiling meats, melting cheese, and toasting bread. The element measures 15 3/8 inches from the front to the mounting bracket. It measures 12-1/4 inches wide, and 3 1/4 inches from the bracket to the terminal end. The mounting holes are 11-1/2 inches apart.

You should replace the broil element if it becomes faulty or damaged. Causes of a bad broil element can include regular wear and tear, overheating, or electrical issues that prevent it from heating up properly.

Symptoms of a bad broil element include:

• The broil element not heating up
• Uneven heating during the broiling process
• Visible damage or burn marks on the element
• Sparking or unusual noises when the broil function is used

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.
