Kitchenaid Dishwasher KUDS01FLBS0 Won't start or doesn't start

The Dishwasher Fuse Kit is an OEM replacement part for Whirlpool dishwashers. It contains the necessary thermal fuses that protect the dishwasher's electrical system from overheating or short circuits. These fuses are critical safety components that help prevent potential fire hazards or damage to the appliance. When replacing this fuse, the included wire harness must be replaced as well.

Symptoms of a blown dishwasher fuse kit include:

• The dishwasher not turning on or powering up at all
• Error codes related to heating or electrical system issues
• Intermittent power failures during wash cycles

Causes of a faulty fuse kit can include electrical surges, wiring problems, component malfunctions leading to overcurrent situations, or simply wear and tear over time.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Door Switch is an OEM part for Whirlpool dishwashers. It plays a crucial role in ensuring the dishwasher operates only when the door is securely closed. The switch signals the control board that the door is shut, allowing the wash cycle to begin safely.

You should replace the door switch if it becomes faulty or damaged. Causes of a bad door switch can include wear and tear from regular use, electrical issues, or physical damage from forceful closing of the door.

Symptoms of a bad door switch include:

• The dishwasher not starting or stopping mid-cycle
• Error codes related to the door latch or door switch
• The dishwasher operating with the door open (safety issue)
• No response when pressing the start button

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Control Panel is an OEM replacement part for Whirlpool built-in dishwashers. It is the control panel located on the front façade, comprising buttons to select cycles and indicator lights showing progress. This interface allows for efficient operation through simple input of wash selections.

Causes of a failing control panel involve damage to electronic components from moisture exposure over time. Wiring degradation or faulty circuit boards can also disrupt intended functions.

Symptoms of an inadequate control panel include:

• Unresponsive buttons that do not initiate cycles
• Light indicators that do not illuminate properly
• Erratic or unexpected dishwasher behavior

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This dishwasher user interface mounts behind the door console and translates button presses into commands for the main control. Replacing a failed UI restores responsive keys, cycle selection, and indicator lights when the panel stops responding or behaves intermittently.

• Registers button selections and controls indicator LEDs on the console
• Sends inputs to the electronic control to start and manage wash cycles
• Helps resolve unresponsive or intermittent buttons and non-illuminating status lights
• Common symptoms include no panel response, won't start when Start is pressed, or random/erratic panel behavior

• Disconnect power at the breaker before servicing
• Remove inner-door/console screws to access the interface
• Use ESD precautions; seat ribbon/plug connectors fully and route wiring to avoid pinching
• Transfer any re-usable mounting clips as needed, reassemble, and test operation

The Circulation Motor is an OEM part for Whirlpool dishwashers. It is responsible for pumping water through the spray arms to ensure thorough cleaning of dishes during the wash cycle. This motor helps maintain consistent water pressure and flow, crucial for effective dishwashing performance.

Over time, the circulation motor can fail due to factors such as motor wear, electrical issues, or blockages that cause the motor to overheat or become damaged. Regular use and the buildup of debris or hard water deposits can also contribute to motor failure.

Symptoms of a bad circulation motor include:

• Poor cleaning results
• Unusual noises during the wash cycle
• Water not circulating properly
• Dishwasher not completing cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Door Latch is an OEM replacement part for Whirlpool dishwashers. It secures the dishwasher door securely closed during the wash cycle. The latch mechanism works with the door handle to provide a sturdy closure and maintains proper sealing to prevent leaks.

Causes of a bad latch door can include normal wear and tear from repeated opening and closing of the dishwasher door over time. Components like springs or latches may lose tension.

Symptoms of a bad latch-door include:

• The door not closing or latching properly
• Difficulty opening or closing the door
• Gaps appearing around the door seal when closed
• The possibility of the door unintentionally opening during a cycle

This OEM Whirlpool replacement part is also compatible with KitchenAid, Jenn-Air, Amana, Roper, and some Kenmore models.

This inner tail ribbon cable transmits signals between the control/display assembly and the main harness, restoring reliable communication for user inputs and display functions. It's a direct replacement designed to match the original connector fit. What it does:

• Carries low-voltage data/signals from the control panel to the main board
• Restores unresponsive or intermittent control panel behavior
• Helps resolve blank or flickering display and erratic touchpad responses
• Maintains proper connector alignment and secure electrical contact

What's included: One inner tail ribbon cable Install notes:

• Disconnect power before beginning any repair to avoid shock or damage
• Handle the cable by the reinforced ends; avoid bending, kinking, or touching exposed contacts
• Ensure connectors are fully seated and retained with original clips or fasteners

The Pump and Motor Assembly is an OEM part for Whirlpool dishwashers. This assembly is responsible for circulating water through the dishwasher during the wash cycle, ensuring that dishes are thoroughly cleaned.

Over time, the pump and motor assembly can fail due to wear and tear, debris buildup, or electrical issues. Regular use, along with exposure to hard water, can cause the components to degrade, leading to performance problems.

Symptoms of a bad pump and motor assembly include:

• Dishes not being cleaned properly
• Unusual noises during the wash cycle
• Water not draining from the dishwasher
• Error codes indicating pump or motor issues

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Strike is an OEM part for Whirlpool dishwashers. This part ensures the dishwasher door latches securely, allowing the dishwasher to operate properly. The strike works in conjunction with the door latch to keep the door closed during the washing cycle.

Causes of a bad strike can include regular wear and tear, physical damage from forceful closing, or misalignment over time. The strike may bend or wear down, preventing the door from latching properly.

Symptoms of a bad strike include:

• Dishwasher door not staying closed
• Dishwasher not starting or stopping mid-cycle
• Loose or misaligned door
• Difficulty in closing the dishwasher door securely

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This run capacitor helps start and keep the motor running smoothly by providing the necessary phase shift and torque boost. A weak capacitor can cause hard starting, humming, or intermittent motor operation.

• Supplies continuous phase shift to maintain motor rotation
• Helps the motor start reliably under load
• Symptoms can include humming, slow or no start, or overheating shutdown
• Restores normal operation when the original capacitor has weakened

• Disconnect power before servicing; discharge the old capacitor safely
• Note wire locations and transfer leads to the new capacitor one-by-one
• Mount securely in the original bracket or location to prevent vibration
• If the motor still won't start, further diagnosis of the motor or start device may be required
