Kitchenaid Range KGRT607HBS8 Won't start or doesn't start

The Oven Burner Ignitor is an OEM part for Whirlpool ranges. This part ignites the gas burner in the oven, providing the necessary spark to start the combustion process that heats the oven.

Causes of a bad oven burner ignitor can include wear and tear from regular use, buildup of food debris or grease, or electrical issues such as a burned-out element or faulty connections.

Symptoms of a bad oven burner ignitor include:

• The oven not heating up or taking a long time to reach the set temperature
• The ignitor not glowing or sparking
• Unusual clicking or buzzing noises during ignition attempts
• The smell of gas without ignition when the oven is turned on

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

The Whirlpool spark module is an OEM replacement part responsible for controlling the ignition and sparking of the gas burners in a Whirlpool range or cooktop. The spark module is typically located behind the control panel or near the burners, and it generates the electrical sparks needed to ignite the gas for cooking.

Causes of a bad module can include electrical surges, physical damage, or simply wear and tear over time.

This part fixes the following symptoms:

• Gas burners fail to ignite or have weak or inconsistent sparks
• Continuous sparking even after the burner is lit
• No spark at all when attempting to ignite the burners
• Unresponsive or non-functional burner control knobs
• Visible damage, such as burn marks or corrosion, on the spark module

The Whirlpool spark module can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Size: Approx 6 inches in length from the sensor tip to the mounting bracket.

Replacement electrode that creates the spark needed to light a gas range or cooktop burner, restoring reliable ignition and consistent burner operation for safe, predictable cooking. What it does

• Produces the spark at the burner to ignite gas when the control is turned on.
• Replaces a cracked, fouled, or non-sparking electrode that prevents burners from lighting.
• Can resolve weak, intermittent, or no-ignition symptoms and reduce continuous clicking.
• Works as the ignition element for the cooktop/range burner assembly.

• Disconnect power and shut off the gas supply before starting any service; allow the appliance to cool completely.
• Handle the ceramic tip and wiring gently—do not force or bend the electrode.
• Use basic hand tools to access and secure the electrode; confirm correct alignment and tight mounting.
