Gdfe10pgj2bb Parts

This user-cleanable fine filter sits in the bottom of the dishwasher and traps small food particles so the wash water stays cleaner. Replacing a damaged or clogged filter helps maintain spray pressure and consistent cleaning results.

• Screens fine debris from the recirculating wash water
• Helps prevent grit and food from redepositing on dishes and glassware
• Supports proper water flow to the spray system and pump
• When clogged or damaged, may cause poor cleaning, gritty residue, odors, or unusual pump noise

• Disconnect power before servicing the appliance
• Open the door and remove the lower rack; unlock and lift out the old fine filter per your model's instructions
• Rinse the area, install the new filter, and lock it securely so it sits flat
• The lower spray arm spins freely before running a test cycle

Factory-configured user interface control board for the dishwasher's control panel. It interprets button inputs, powers the panel lights, and sends commands to the main control. Replace a failed UI board to restore a responsive panel and reliable cycle selection.

• Reads touchpad/button inputs and communicates selections to the main control
• Drives indicator LEDs and panel feedback
• Enables proper operation of Start/Cancel, options, and control lock features
• Common failure signs: unresponsive panel, no lights or beeps, erratic button response, or a unit that won't start despite power

• Disconnect power at the breaker before servicing; verify no voltage at the appliance
• Access the UI board by removing the inner door panel/trim on most models
• Transfer any brackets, shields, or foam insulators from the old board; reconnect harnesses firmly
• Handle electronics with ESD care; route wiring to avoid pinches and test all keys after reassembly

This drain hose elbow creates a secure 90-degree connection in the dishwasher's drain line, helping route the hose cleanly while maintaining good flow. It supports a tight, leak-resistant turn where space is limited, reducing kinks and misrouting.

• Provides a 90-degree turn for the dishwasher drain hose to aid proper routing and flow
• Helps reduce kinks or crushing at tight bends that can slow or stop draining
• Forms a secure connection point to help prevent leaks at the hose junction
• Common symptoms of a failed or damaged elbow include leaks under the sink, visible cracks, kinks, or slow/poor draining

• Disconnect power and water supply; place a towel or pan to catch residual water
• Ensure the hose is fully seated on the elbow and secured with appropriate clamps per your model
• Route the drain line with a high loop or air gap as required by local code
• Run a short cycle and check all connections for leaks

This twist-lock clip secures the dishwasher's heating element to the tub floor, keeping it properly positioned for effective water heating and drying. Replacing a broken or missing clip stops rattles and keeps the element stable during cycles.

• Locks the heating element to the tub/base with a twist-to-secure design
• Maintains correct element alignment and clearance
• Helps reduce rattling or scraping noises from a loose element
• Common signs: element sagging or out of place, broken/missing clip, poor drying results

• Disconnect power at the breaker and allow the heating element to cool before servicing
• Remove the lower rack to access the clip on the tub floor
• Rotate the old clip to release; position the new clip over the mounting slot and twist to lock
• Ensure the element is fully seated in the clip and not contacting the tub or spray arm

This is a 6-20 machine screw, 3/8 inch length, used to secure trim, panels, or small components on compatible cooking appliances. Replacing a missing or damaged screw helps keep parts tight and prevents rattles or shifting during use.

• Fastens brackets, panels, or trim in the appliance chassis
• Helps restore a secure fit when the original screw is stripped or lost
• Can resolve issues like loose trim, minor rattling, or misaligned panels
• Nickel finish for corrosion resistance in warm, humid environments

• Disconnect power and allow appliance to cool before servicing
• Remove only the necessary adjacent fasteners to access the mounting point
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing
• Replace any missing clips or spacers originally used with the screw

The DC Harness is an OEM part for GE dishwashers. It is an important electrical component that routes power between components and allows the dishwasher to operate properly during each cycle. Issues can arise over time due to normal wear and tear on wiring insulation or repeated flexing during door openings.

Causes of a bad DC Harness can include frayed or exposed wiring, broken wire connections, or damaged insulation.

Symptoms of a bad DC Harness include:

• Lights or displays not working properly
• Motor not functioning during cycles
• Delays or failure to complete cycles
• Strange noises coming from the control module
• Intermittent or complete failure to operate

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.


This gray dishwasher vent releases moist air from the tub during the dry cycle on hybrid-dry models. Replacing a damaged vent helps control steam and condensation for more consistent drying and a cleaner door area.

• Directs steam out of the tub during hybrid drying
• Helps reduce interior condensation for improved drying results
• If cracked, warped, or loose, you may notice steam escaping at the door, moisture on the console, or dishes that stay wet
• Visible damage or discoloration around the vent area can indicate replacement is needed

• Disconnect power at the circuit breaker before servicing
• Access is typically through the inner door panel; handle sharp edges and note original orientation
• Ensure the vent seats evenly and fasteners are secure without overtightening
• Run a short cycle and check for proper venting/steam control after reassembly

This UI board housing mounts in the top-control area of the dishwasher door and secures the user interface control board. It restores a solid, factory fit so buttons align and operate consistently without wobble or shift.

• Mounts and supports the user interface (UI) control board at the top of the door
• Aligns the buttons/touchpad with the board for proper actuation
• Helps protect the board and reduces vibration inside the door cavity
• Damage can lead to loose or misaligned controls, sticking buttons, rattling in the control area, or the UI shifting out of place

• Disconnect power at the breaker before servicing
• Remove the inner door panel screws to access the UI assembly
• Transfer the UI board and any clips/gaskets to the new housing; reuse existing fasteners
• Handle electronics with ESD precautions and keep wire harnesses clear during reassembly

The Flat Chrome Badge is an OEM part for GE refrigerators. It is responsible for displaying the GE logo and model information on the front of the refrigerator. As an identifiable brand marker, the badge contributes to the overall appearance and style of the appliance.

Causes of a bad badge can include damage from impacts or bending, discoloration or tarnishing over time, or simple wear and tear that renders the badge appearance faded or illegible.

Symptoms of a bad badge include:

• A missing, loose, crooked or illegible badge
• Signs of denting, scratching or corrosion
• An outdated or inconsistent badge that doesn't match the model

This GE replacement part is compatible with Hotpoint, RCA, and some Kenmore models.

This 10-32 x 1/4-inch zinc-plated screw secures internal panels and hardware in select dishwashers. Replace a missing, stripped, or corroded fastener to restore a tight fit and help prevent vibration or loosening during operation.

• Fastens brackets, panels, or components that use a 10-32 machine thread
• Replaces hardware that is missing, stripped, or rusted
• Helps reduce rattling or vibration from loose assemblies
• Supports proper component alignment for reliable operation

• Disconnect power and water supply before servicing the appliance
• Remove the old fastener and verify thread size and length match before installation
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Replace damaged clips, nuts, or inserts that won't hold a 10-32 screw securely

This dishwasher fill funnel guides water flow into the appropriate channel, helping ensure proper distribution during wash cycles. Replacing a warped or damaged funnel can prevent leaks and restore consistent spray performance.

• Directs water into the dishwasher's internal water feed path
• Helps maintain correct water pressure for spray arms
• Common failure signs: leaking at the funnel area, poor spray performance, residue on dishes, or misalignment with the water feed tube
• Physical damage, warping, or a loose fit are typical replacement indicators

• Disconnect power and turn off water supply before servicing
• Access from inside the tub; remove any retaining screws or clips
• Inspect and reuse existing hardware/seals if still in good condition
• After installation, run a short cycle and check for leaks or misalignment

This thermistor assembly is the dishwasher's temperature sensor. It monitors water temperature so the control can heat and time cycles correctly. Replacing a faulty sensor restores accurate temperature feedback and more consistent wash performance.

• Monitors wash-water temperature and reports it to the control
• Helps regulate heater operation and cycle progression
• A failing sensor may cause extended or incomplete cycles
• Can contribute to poor cleaning from low wash temperatures or temperature-related error codes

• Disconnect power at the breaker before servicing
• Access the sensor at the sump/tub area; release the locking tab/clip to remove, and seat the new sensor fully to ensure a proper seal
• Reconnect the wire harness securely and run a test cycle to check for leaks

This fill funnel hose directs incoming water from the inlet assembly into the tub through the fill funnel. Replacing a worn or cracked hose helps stop leaks and restores a reliable, sealed fill path for consistent wash performance.

• Carries water from the inlet assembly through the fill funnel into the tub
• Maintains a watertight path to prevent external leaks
• Symptoms of failure: dripping during fill, puddles beneath the unit, or visible cracks/splits in the hose
• A significant leak may lead to low water level or extended fill times

• Disconnect power and shut off the water supply before servicing
• Remove the toe-kick/kickplate; pulling the dishwasher forward may be needed for access
• Place a towel or pan to catch residual water; move clamps, remove the old hose, and fully seat the new hose on both fittings
• Re-secure clamps, restore water and power, and run a short fill to check for leaks before reinstalling panels

This control box top is the plastic cover that protects the appliance's control board and user controls while keeping the front of the console finished and safe. It helps prevent dust, moisture, and accidental contact with internal electronics. What it does

• Covers and protects the control board and internal wiring behind the console.
• Provides the mounting surface and openings for buttons, knobs or touch interfaces.
• Prevents dirt, lint, and moisture from reaching sensitive electronics.
• Restores a secure, finished appearance to a damaged or cracked console area.

• Always disconnect power to the appliance before beginning work to avoid electrical shock.
• Remove any bezel, screws or clips securing the old top and transfer any required mounting hardware or trim pieces.
• Handle the control board and connectors with care; avoid touching circuit components or bending contact pins.

Restore your appliance's factory look with this badge assembly. It replaces a missing, cracked, or faded logo on the refrigerator exterior, delivering a clean, professional appearance without affecting performance or operation.

• Decorative nameplate/logo for the refrigerator exterior
• Replaces cracked, faded, loose, or missing badge
• Restores a clean, factory appearance
• Cosmetic component; does not impact cooling or function

• Disconnect power before servicing the appliance
• Protect the finish; use a plastic trim tool to remove the old emblem if needed
• Clean and dry the mounting area; align with locating marks/holes and secure per your model diagram

The Wash Pump Kit is an OEM component specifically designed for GE dishwashers. The wash pump works diligently during cycles to circulate water containing detergent throughout the dishwasher, providing optimal cleaning.

Causes of a bad wash pump can include mineral buildup in pump components due to hard water, worn seals or bearings from continuous use, or damage from foreign objects in dishes obstructing the pump.

Symptoms of a bad Wash Pump Kit include:

• Dishes not getting fully cleaned after cycles
• Standing water remaining in the bottom of the dishwasher
• Strange noises or vibrations coming from the pump area
• Error messages related to water detection or draining issues

Replace yours today with this genuine OEM GE part for reliable water circulation during each cycle. This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
