Pgr366lp/01 Parts

This deflector directs dishwasher spray water for proper coverage and helps protect nearby components from direct spray. It replaces broken or warped deflectors to restore intended water flow and cleaning performance. What it does

• Guides spray water toward dishes and spray arms to maintain even coverage
• Prevents direct spray from hitting sensitive components or seals
• Helps reduce spotting and uneven cleaning caused by misdirected water
• Fits where the original deflector is mounted; replaces cracked, broken, or deformed pieces

• Turn off power and water supply to the appliance before starting any repair
• Remove the lower rack or other obstructions for clear access to the mounting area
• Inspect mounting tabs and surrounding components; replace any damaged clips or fasteners

A 9-inch gas supply tube that routes fuel from the appliance inlet to the control valve/manifold, restoring proper gas delivery for safe, consistent burner operation when tubing is damaged or leaking. What it does:

• Channels gas to the control valve/manifold so burners can ignite and maintain a steady flame.
• Replaces bent, punctured, corroded, or leaking tubing that can interrupt fuel flow.
• Helps address common symptoms such as a gas odor near the appliance, burners that won't light, or low/uneven flames.
• OEM-style replacement designed for the corresponding Bosch gas appliance configurations.

• Shut off the gas supply and electrical power to the appliance before starting any work.
• Use correct fittings and approved thread sealant or gasketing; tighten to OEM-recommended torque if specified.
• After installation, perform a soap-and-water or approved leak test; if you detect a leak, shut off gas.

This compression sleeve forms the sealing ring for a 5/16-inch tubing compression joint, restoring a watertight connection when used with a matching compression nut and fitting. Ideal for stopping leaks and restoring reliable water lines. What it does:

• Creates the compression seal on 5/16" tubing when installed with a compatible compression nut and fitting.
• Stops leaks or drips at compression-style water connections.
• Used on appliance water lines (ice makers, water inlets) and other 5/16" tubing joints.
• Replaces worn or damaged sleeves that fail to hold a tight seal.

• Shut off the water supply and relieve pressure before working on water lines.
• Inspect and cut tubing squarely; slide the sleeve onto the tube before threading the compression nut and fitting.
• Tighten the compression nut per the fitting manufacturer's instructions and check the joint for leaks.
• Replace the sleeve if damaged or deformed.

This is a compression nut for 5/16-inch tubing. It secures the tubing to a compatible compression fitting to create and maintain a tight, reliable connection.

• Clamps 5/16-inch tubing onto a matching compression fitting when tightened
• Helps restore a secure seal at a leaking or loose compression joint
• Useful when threads are stripped, the original nut is cracked, or the connection won't hold tension
• Common signs include drips at the fitting, inability to tighten, or visible thread damage

• Shut off the supply and allow the system to depressurize before service
• Use appropriately sized wrenches; avoid overtightening to prevent damage
• Inspect the ferrule/olive and tubing end; replace if worn or distorted
• After installation, restore supply and check for leaks at the connection

This transformer supplies the low-voltage power needed for an oven's interior lights so bulbs operate reliably. It restores proper lighting and helps stop flicker or complete loss of oven lamp function. What it does:

• Converts the oven's supply to the low-voltage output required by interior lamp circuits.
• Restores steady lamp operation when lights fail to come on or flicker.
• Works with the oven's light switch and control circuitry to deliver consistent voltage.
• Helps prevent false diagnostics caused by intermittent lamp power.

• One oven light transformer.

• Disconnect all power to the appliance before starting any repair.
• Accessible behind the control panel or chassis; remove panels carefully to reach the transformer.
• Note wire locations and secure all connectors; use proper wire connectors and strain relief.

This display is the user interface module that shows cycle status, settings and error indicators so you can read and control the appliance from the front panel. It restores visible feedback and menu information for normal operation. What it does

• Provides the visible display for cycle progress, timers and selected options
• Shows error codes and status messages to help identify issues
• Works with the appliance control board to update settings and user inputs
• Restores readable display after a failed or cracked panel

• Disconnect power to the appliance before starting work to avoid shock or damage
• Replacement typically requires removal of the front control or console panel; handle the display lens and ribbon connectors carefully
• Keep screws and small fasteners organized for reassembly

A cable harness that routes and connects power and signal wires to restore proper electrical continuity and control communication in your appliance. Replaces a worn or damaged harness to help eliminate intermittent power or control faults. What it does:

• Provides bundled wiring and connector interfaces between control boards, motors, sensors, and switches
• Restores reliable electrical connections when original wires or terminals are frayed, broken, or corroded
• Can resolve symptoms such as intermittent operation, loss of power to components, or control panel communication errors
• Matches OEM connector types and wire routing to maintain correct electrical function

• Disconnect all power (unplug appliance or switch off breaker) before starting service
• Note wire routing and connector positions during removal to ensure correct reinstallation
• Handle connectors by the housing; avoid pulling on individual wires

This panel insert replaces a damaged or missing control-panel trim piece to restore the front appearance and support proper button alignment and sealing. It fits into the appliance's control area for a clean, finished look. What it does:

• Replaces cracked, faded, or otherwise damaged control-panel insert pieces
• Restores cosmetic finish and proper fit for control buttons and overlays
• Helps maintain a sealed control area against moisture and debris
• Prevents loose or misaligned panel edges that can interfere with operation

• Disconnect power to the appliance before starting any repair
• Handle edges carefully to avoid scratching or cutting; wear gloves if needed
• May require removal of the outer door or control bezel—use proper tools and follow the service manual

This mounting bracket secures internal components to the appliance frame to restore proper alignment and reduce movement. It's a simple replacement that helps eliminate rattles and keeps parts firmly in place. What it does:

• Provides a secure anchor point for internal parts to stop shifting during operation
• Prevents rattling, squeaking, or vibration caused by loose components
• Helps restore proper alignment when panels or assemblies sag or sit unevenly
• Replaces cracked or bent brackets that can cause part wear or misfit

• One mounting bracket

• Disconnect power and water before starting any repair
• Access may require removing panels or trim to reach the bracket location
• Use common hand tools (screwdriver, nut driver) and retain hardware for reuse
• Inspect surrounding clips and fasteners and replace any that are damaged for a secure fit

This panel insert is the replacement control-panel trim that restores a clean, finished look and protects the console area from scratches and wear. It fits into the console to cover and support the control surface. What it does:

• Replaces cracked, scratched, or cosmetically damaged control-panel trim
• Protects underlying buttons and electronics from everyday wear and spills
• Restores a uniform appearance to the appliance front for a like-new finish
• Helps ensure control buttons and labels sit correctly in the console area

• Disconnect power to the appliance before starting any repair
• Access may require removal of the console or outer door; follow the OEM service manual
• Handle the insert carefully to avoid scratches; align tabs/clips before applying pressure

This temperature display assembly provides the front display used to show oven temperature and user feedback, restoring a clear, readable temperature readout and control indications. What it does:

• Displays current oven temperature and control/status information on the front panel
• Replaces cracked, dim, faded, or non-responsive temperature display components
• Helps resolve symptoms like unreadable characters, intermittent or blank temperature readout, or incorrect display feedback
• Interfaces with the control board to present user temperature and mode information

• Disconnect power to the appliance before starting any repair to avoid shock or damage
• Handle the display and any attached ribbon cables or connectors carefully to avoid damage
• Installation typically requires removing the control panel or oven door trim to access the display assembly
• After installation, restore power and verify the display shows temperature and control information correctly

The Wire is an OEM part for Bosch ranges and ovens. It serves as the critical electrical pathway that connects various components within the appliance, enabling power distribution and communication between different systems.

Causes of a malfunctioning Wire can range from exposure to high temperatures over time, which can degrade the wire insulation and lead to short circuits, to physical damage from impact or improper installation. Rodent activity can also contribute to chewed or damaged wiring.

Symptoms of a bad Wire in a range or oven can include:

• Certain cooking functions or modes not working correctly
• Error codes related to electrical or communication issues
• Flickering or malfunctioning oven lights or displays
• Burning smells or visible damage to the wiring insulation

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Broil Solenoid is an OEM part for Bosch ranges. The solenoid receives a signal from the range’s control board and operates based on internal coil and plunger mechanisms. When activated, it opens the gas valve or switches electric current to energize the broil element positioned above the oven cavity.

Symptoms of a faulty broil solenoid can include:

• Inability to initiate or sustain broiling despite selecting the function
• Delayed broil ignition or shutoff not matching timer settings
• Gas smell or abnormal burner activity from improper valve control

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

A Trident-style surface burner head that directs gas to the cooktop burner for an even, controlled flame. Replaces a worn or damaged burner head to restore consistent heating and safe operation. What it does:

• Directs and shapes the gas flame for proper cooking heat
• Restores even flame pattern when the original burner is warped or clogged
• Helps eliminate weak or irregular flames caused by damaged ports
• Works with the burner base and cap to maintain stable ignition

• Turn off the appliance and shut off gas/electric power before servicing
• Remove grates and burner cap, then replace the burner head; reassemble in reverse order
• Clean mating surfaces of debris or corrosion before installation for proper fit
