Speedqueen D510139P Blower Fan Assembly OEM Part

Product Details

Genuine Speedqueen part. See all items in Dryer Blower Wheel Or Fan Blade.

Cross Reference Information

Part Number D510139P replaces AP6285642, 510139P, 510139, 56000.

Description

Considered a crucial part of the dryer, the blower fan assembly is the part that pulls in air from outside and then circulates that air in the drum to ensure clothing gets dry. After the air is moved around the drum, it is then moved through the exhaust vent. This part is located on the motor shaft and is made of durable plastic. Regular use can lead to wear and tear or damage to this component. If this occurs, the air in the dryer may not dry the clothing. In this case, the blower fan assembly will need to be replaced.If the blower fan assembly needs to be replaced, first the dryer should be unplugged from power. Take the cabinet top off and remove the front panel on the appliance. Take out the drum, remove the motor clamp, and loosen the blower fan so it can be removed. Take it out and replace it with the new blower fan assembly.The blower fan assembly is designed to be used with dryers manufactured by Amana and Speed Queen. It is sold as an individual part. This is an authentic OEM replacement part that is sourced directly from the manufacturer.
