Speedqueen 804428P Door Boot Seal (Black) OEM Part

Product Details

Genuine Speedqueen part. See all items in Washer Gasket & Seal.

Cross Reference Information

Part Number 804428P replaces AP5983726, 804428.

Description

This black door boot seal forms a watertight barrier between the door and front tub on a front-load washer, keeping wash water contained. Replace a worn or torn seal to stop leaks and restore reliable operation. What it does

• Seals the gap between the door and front tub to prevent water leaks
• Helps direct water back into the drum during operation
• Maintains proper containment when filling, washing, and spinning
• Common failure signs: water leaking from the door/front, visible tears or cracks, or the gasket pulling loose

What's included

• Includes: 1 black door boot seal

Install notes

• Disconnect power and turn off water supply before servicing
• Open the door and carefully release the inner and outer retaining clamps/springs
• Note the seal's orientation (alignment marks/drain ports) and install the new seal the same way
• Ensure both inner and outer lips are fully seated; reinstall clamps and run a short test cycle to check for leaks

Also known as: door gasket, door boot, bellow
