Speedqueen 808196P Drain Pump Assembly (100–127V, 60 Hz), Yellow OEM Part

Product Details

Genuine Speedqueen part. See all items in Washer Pump.

Cross Reference Information

Part Number 808196P replaces AP7205646, 805724P, 803921P.

Description

This drain pump assembly removes wastewater from the tub during the drain and spin cycles, helping your washer empty quickly and complete cycles reliably. Replace a failing pump to fix standing water, aborted cycles, or drain-related error codes. What it does:

• Pumps water from the tub to the household drain during drain and spin
• Restores proper draining so cycles can finish as intended
• Common failure symptoms: no or slow draining, water left in tub, loud humming/grinding from the pump area, small leaks near the pump, or drain fault errors
• 100–127V, 60 Hz "yellow" variant per OEM specification

What's included:

• One drain pump assembly

Install notes:

• Disconnect power and turn off water supply before servicing
• Expect residual water; place towels or a pan to catch spills
• Note hose and wire positions; transfer any mounting hardware from the old pump
• Inspect and clear the drain hose and tub-to-pump hose for blockages before testing for leaks
