Speedqueen D517256 Electronic Wiring Harness (1-Phase, With Indicator Light) OEM Part

Product Details

Genuine Speedqueen part.

Cross Reference Information

Part Number D517256 replaces AP6995582, 513986, D513986.

Description

This electronic wiring harness connects the control components and provides the indicator light needed for proper operation of a 1-phase Speed Queen washer. It replaces a damaged or worn harness to restore electrical continuity and visual status feedback. What it does:

• Links the control board, switches, sensors and indicator light so commands and status signals pass correctly
• Provides the harness routing and connector set used on compatible 1-phase washer control assemblies
• Commonly replaced when the machine has no power to controls, no indicator light, or intermittent control operation
• Helps resolve electrical faults caused by chafed wires, broken terminals, or connector failure

What's included: One complete wiring harness assembly Install notes:

• Disconnect power before servicing to avoid shock or damage
• Handle connectors gently; match keyed connectors and secure all locking tabs
• Route harness away from sharp edges, hot components and moving parts; follow OEM routing and fasteners
