Speedqueen D510190P Terminal Block Assembly (With Screws) OEM Part

Product Details

Genuine Speedqueen part. See all items in Dryer Terminal Block, Receptacle.

Cross Reference Information

Part Number D510190P replaces AP6285204, 510190P, 510190, 61923, 61923P, R0605088.

Description

This terminal block assembly connects your dryer's power cord to the internal wiring, providing a secure, heat-resistant junction. Replacing a damaged block restores a reliable electrical connection and helps prevent intermittent power, overheating, or burnt terminals.

• Provides an insulated junction point between incoming power and the appliance's internal wiring
• Secures cord conductors with screw terminals to maintain a tight, low-resistance connection
• Helps resolve issues like the dryer not powering on, intermittent shutdowns, or a burning smell near the cord cover
• Replaces cracked, melted, or stripped terminals to restore a safe power path

What's included: Terminal block assembly with screws. Installation notes:

• Disconnect power at the breaker before servicing
• Photograph/label wire positions and move one wire at a time to the new block
• Tighten terminal screws firmly; recheck connections after initial operation
• Inspect/replace any heat-damaged cord lugs, wiring, or strain relief before reassembly
