Speed Queen 204266 Capacitive Touch Switch (Control Panel) OEM Part

Product Details

Genuine Speed Queen part.

Cross Reference Information

Part Number 204266 replaces AP6880523.

Description

This capacitive touch switch mounts behind the console and senses finger presses through the overlay, sending a signal to the control board. Replacing a failed switch restores consistent response from the affected touch button on touch-control machines.

• Detects user input at the touch area and communicates it to the main control
• Used for functions tied to specific keys (e.g., start, options, selections)
• Common failure signs: no response from a particular key, intermittent input, or needing excessive pressure
• Prevents a cycle from starting if the Start/Enter key's switch has failed

Includes: 1 capacitive touch switch. Install notes:

• Disconnect power to the appliance before servicing to avoid electrical shock
• Access the console/control area; note connector orientation and wire routing
• Install the new switch in the same position and orientation as the original
• Use ESD protection when handling electronics; reassemble and verify keypad operation
