Speedqueen D513710 Cylinder Glide (Rulon 488), 1-Piece OEM Part

Product Details

Genuine Speedqueen part. See all items in Dryer Bearing.

Cross Reference Information

Part Number D513710 replaces AP6284702, 510188, 513710, 501676, 503452, 510187.

Description

This Rulon 488 cylinder glide supports the front edge of the dryer drum at the bulkhead. Replacing a worn glide restores smooth, quiet rotation and helps eliminate scraping or squealing from the front of the drum.

• Provides a durable, low-friction surface between the drum rim and front bulkhead
• Supports the drum to minimize drag and wear for quieter operation
• Worn glide may cause scraping/squealing noises or a dragging drum
• Visible flat spots, grooves, or excessive wear on the glide indicate replacement

What's included: One cylinder glide (Rulon 488). Install notes:

• Disconnect power and shut off gas supply before servicing
• Access the front bulkhead and support the drum to relieve load on the glide
• Remove the worn glide and clean the mounting area; install the new glide in the same position/orientation per factory fasteners
• Rotate the drum by hand to inspect felt seals and any additional glides and replace if worn
