Speedqueen D513505 Fabric Selector Switch (3-Position) OEM Part

Product Details

Genuine Speedqueen part. See all items in Dryer Switch.

Cross Reference Information

Part Number D513505 replaces AP6284700, 513505, 503997, 510212.

Description

This 3-position fabric selector switch is the control behind the knob that lets you choose the fabric setting on your unit. Replacing a worn switch restores positive detents and ensures your selection is recognized instead of ignored or stuck.

• Provides three selectable fabric settings to tailor operation
• Routes the chosen setting to the timer/control
• Typical symptoms: no response when changing settings, intermittent selection, or being stuck on one mode
• Physical clues of failure: loose/no detent feel, broken shaft, or heat-discolored terminals

What's included: One 3-position fabric selector switch Installation notes:

• Disconnect power before servicing
• Access the control console; remove the knob and retaining hardware to free the old switch
• Photograph/label wire positions and transfer each lead to the same terminals on the new switch
• Reassemble and test all three positions for proper engagement
