Speedqueen 201609P Pressure Switch (Variable) OEM Part

Product Details

Genuine Speedqueen part.

Cross Reference Information

Part Number 201609P replaces AP3882196, 201609, 2024909.

Description

This variable pressure switch senses water level and signals the washer to stop filling, helping maintain correct fill levels for reliable cycles. It replaces a failed or intermittent level-control switch to restore normal filling behavior. What it does:

• Detects drum water level and tells the control when to stop filling
• Helps prevent overfilling or underfilling caused by a bad level signal
• Resolves symptoms like no fill, overfill, or erratic cycle advancement
• Works as the washer's water-level sensor interface to the main control

What's included:

• One variable pressure switch

Install notes:

• Disconnect power (and water if applicable) before servicing
• Replace only with the exact part number; match electrical connector and hose fittings
• Handle the pressure hose and terminals carefully to avoid damage
