Speedqueen D510702 Dryer Limit Thermostat (Black) OEM Part

Product Details

Genuine Speedqueen part. See all items in Dryer Fuse Or Sensor.

Cross Reference Information

Part Number D510702 replaces AP6285127, 510702, 61886.

Description

This limit thermostat monitors dryer temperature and opens the heating circuit if temperatures climb too high, helping protect the appliance and laundry. Replacing a failed thermostat restores reliable heat and safe temperature control. What it does:

• Monitors temperature at the heater/blower housing and opens at its limit to prevent overheating
• Helps maintain safe drying temperatures during normal cycles
• Common symptoms of a failed thermostat: no heat or intermittent heat, dryer runs too hot/overheats, or cycles end early due to overheating

What's included:

• 1 limit thermostat

Install notes:

• Disconnect power and, if applicable, shut off gas before servicing
• Access the thermostat location per your model (typically on the heater housing or blower duct), remove mounting screws, and note wire positions
• Transfer wires to the new thermostat and mount it flush for proper sensing
• After reassembly, clear lint and verify venting/airflow to prevent repeat overheating
