William A Lebanon , NJ September 21, 2016 Appliance: Model VDSC365-6BSS Viking range oven door hinges failure causing door to easily drop Replaced hinges. It was a bit tricky, as you first have to open the door fully and move tabs to allow for removal. I had difficulty locating the tabs, until I exposed them by manually pulling the door away from the hinges. I then closed the door to the 'broil' position and pulled off the door. Removed the 2 screws holding each hinge. Struggled to remove hinges as they were damaged and are a tight fit. Installed new hinges which was somewhat difficult with assistance from rubber hammer. Then found I couldn't install screws. Removed hinges and found that the screws are self-tappers, but wouldn't go into hinges as the screws were worn. I then used a 8-32 tap to tap the hinges. Reinstalled hinges and door. I should have purchased replacement screws. WEAR WORKING GLOVES, AS THE HINGES HAVE SHARP EDGES! Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Annlyn L Montville , NJ March 28, 2016 Hinges broke on my viking oven door Replaced the hinges. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
Daniel N Canfield , OH May 15, 2016 Appliance: Model VGSC3676BSS Broken oven door hinge on viking range Remove door by sliding off hinge, remove 2 screws, upper and lower at hinge location, replace hinge and reinstall screws. approximately 10 minutes completion time. REQUIRED GREEN SPRING Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Pliers, Screwdrivers
James D Kure Beach , NC December 21, 2019 Appliance: Model VDSC3676BSS The hinges on the oven were bent due to downward pressure on the door when it was open this caused the door to not seal and shut correctly I ordered new hinges and replaced the bent ones. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
