Viking PM010129 Relay (25A) OEM Part

Product Details

Genuine Viking part.

Cross Reference Information

Part Number PM010129 replaces AP5317437, 940531, PM010026.

Description

This 25-amp relay switches high-current components in your appliance on and off as directed by the control system. Replacing a failing relay restores consistent power to elements or motors and helps resolve intermittent, no-heat, or non-running issues.

• Controls power to high-demand components when signaled by the control
• Opens/closes the circuit to keep heavy current away from sensitive electronics
• Common failure symptoms: no heat or fan operation, intermittent cycling, or clicking without activation
• Helps correct erratic operation caused by pitted or stuck contacts

What's included: 1 relay Install notes:

• Disconnect power at the breaker and verify no voltage before servicing
• Photograph and label wiring; transfer leads to matching terminals one at a time
• Mount securely in the original orientation; ensure tight, clean spade connections and replace any heat-damaged terminals
• Restore power and test operation
