Whirlpool WP8524472 Door Latch Actuator OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP8524472 replaces AP6012867, 8524472, 8270116, 904714, PS11746084.

Description

This latch actuator links the door lock mechanism on select ranges and wall ovens, engaging and releasing the door as designed. Replacing a worn or bent actuator restores smooth latch movement and reliable door locking during normal use and self-clean cycles. What it does:

• Transfers motion within the latch assembly to lock and unlock the oven door
• Helps the door lock engage for self-clean and release when complete
• Addresses issues like a door that won't lock/unlock or latch fully
• Can resolve incomplete self-clean cycles caused by a misaligned or damaged latch linkage

What's included:

• 1 latch actuator

Install notes:

• Disconnect power at the breaker before servicing
• Access the latch assembly per your model's service/parts diagram
• Note the actuator's orientation and any linkage/spring positions before removal
• Verify smooth manual latch operation before reassembling and restoring power
