Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WP9709575 replaces AP6013806, 9709575, 4439081, PS11747033.
Description
This silver Planetary assembly is the lower drive unit of a stand mixer that carries the beater shaft. Replacing a worn or loose planetary restores smooth, consistent planetary motion and reliable attachment rotation for dependable mixing performance.
- Transfers motor power to the beater and creates true planetary mixing action
- Houses the beater shaft and interfaces with the lower gear train
- Helps maintain stable beater-to-bowl alignment at the bottom of the mixer head
- Typical failure symptoms: beater not turning or stalling, grinding/clicking from the lower head, or noticeable wobble/excess play in the planetary
What's included: 1 silver planetary assembly Install notes:
- Unplug the mixer and remove the bowl and beater before service
- Drive out the roll pin to remove the old planetary; transfer and reuse any model-specific hardware
- Clean and re-grease gears with food-grade mixer grease during reassembly, if needed
- Reinstall the planetary and pin; verify beater-to-bowl clearance per the owner's manual before use
