Whirlpool W11509400 Base Chassis (30" Gas Freestanding Range), 1 Count OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11509400 replaces AP7187070.

Description

This base chassis is the lower frame assembly for a 30" gas freestanding range. It provides structural support and alignment for the cooktop, oven cavity, and mounted components to restore safe, stable operation. What it does:

• Supports and secures the cooktop, oven cavity and internal components
• Maintains proper alignment for the oven door and drawer assemblies
• Reduces movement, rattling or sagging of the range base
• Provides mounting points for panels, brackets and serviceable parts

What's included: One base chassis assembly. Install notes:

• Disconnect electrical power and shut off gas supply before service.
• Use proper lifting technique; chassis assemblies can be heavy—two people recommended.
• Follow OEM service manual for removal and reinstallation steps, torque, and fastener locations.
• After installation, check connections and test appliance operation and gas fittings for leaks.
