Whirlpool W10860146 Defrost Thermostat (Bi-Metal) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Defrost Thermostat, Sensor.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10860146 replaces AP6003920, W10299078, 4455206, PS11731475.

Description

This defrost thermostat senses evaporator temperature to control the defrost heater. Replacing a failed thermostat restores proper defrosting, prevents overheating during the defrost cycle, and helps maintain stable cooling performance.

• Monitors evaporator coil temperature and closes to power the defrost heater during defrost
• Opens the heater circuit as the coil warms to terminate defrost and prevent overheating
• Helps clear frost from the evaporator so air can circulate between freezer and refrigerator
• Failure may present as heavy frost/ice buildup, reduced cooling in the fresh food section, the evaporator fan hitting ice, or a defrost cycle that fails to start

What's included: One defrost thermostat Install notes:

• Disconnect power before servicing; defrost heavy ice as needed for access
• Located on/near the evaporator coil behind the freezer's rear panel, typically clipped to tubing
• Match original clip orientation and wire routing; ensure firm thermal contact with the coil/tube
• After installation, confirm operation with a continuity check at freezer temperature or run a manual defrost test per the service manual
