Whirlpool W10323042 Door Bin (Cantilever) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10323042 replaces AP5955583, 2222922, 3449049, PS10063532.

Description

This cantilever door shelf bin hooks into the refrigerator door liner to hold bottles, jars, and condiments. Replacing a cracked or missing bin restores secure, organized storage and helps prevent items from tipping when you open the door.

• Provides on-door storage for frequently used items
• Cantilever design hangs on molded slots in the door liner
• Common failure signs: cracked plastic, broken tabs, bin won't stay in place, or falls off
• Restores usable door space and helps keep contents stable during door movement

What's included: 1 door shelf bin Install notes:

• Disconnect power before servicing for safety
• Remove items from the bin area and lift the old bin up and out
• Align the new bin's hooks with the door slots, then press down until fully seated
• Do not force; verify correct position and orientation, as doors can use different bin sizes
