Whirlpool WPW10134774 Ice Crusher Bin (Lower) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10134774 replaces AP6015551, W10134774, 1470469, PS11748832.

Description

This lower ice crusher bin is the bottom housing of the freezer's ice container. It supports the auger and crusher assembly to help prevent jams and leaks, so your dispenser can reliably deliver cubed or crushed ice.

• Holds and guides ice within the dispenser assembly
• Supports the auger/crusher mechanism for consistent dispensing
• Channels ice toward the chute for cubed or crushed selection
• Common symptoms of a failed bin: ice not dispensing, selection stuck between cubed/crushed, leaks in or around the bucket, rattling or grinding sounds

What's included: 1 lower ice crusher bin Install notes:

• Turn off the ice maker and disconnect power before servicing
• Remove the ice bucket from the freezer door and empty remaining ice
• Transfer the auger/crusher components and any reusable hardware from the old bin to the new bin as required by your model; keep parts in the same order
• Reseat the bucket, ensure the drive coupler engages, restore power, and test both cubed and crushed functions
