Whirlpool WP67006390 Hv Control Box (Electrical Control Module) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP67006390 replaces AP6010509, 67006390, 12957601, 12957601SP, 4435670, PS11743690.

Description

This HV control box is the electrical control module that routes power and switching signals for the appliance's high-voltage circuits, restoring correct power delivery and control when the module has failed. What it does:

• Controls and distributes high-voltage power to heating and/or motor circuits in the appliance.
• Replaces a failed control module that can cause intermittent or complete loss of heating or operation.
• Common symptom: appliance runs but does not heat or perform expected functions.
• Common symptom: appliance is unresponsive or has inconsistent power to components.

What's included: One HV control box. Install notes:

• Disconnect power (unplug or shut off breaker) before servicing to avoid electrical shock.
• Only install on compatible models and verify fit; consult model-specific service literature.
• Avoid touching terminals; secure all wiring connections and mounting hardware before restoring power.
