Whirlpool WPW10398575 Burner Inner Cap (Inner Burner Cap), 1 Each OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10398575 replaces AP6020918, W10398575, 2118467, PS11754238.

Description

This burner inner cap is the small metal cap that sits on the center of a gas cooktop burner head to help direct and shape the flame for even heating. Replacing a damaged or misplaced cap restores correct burner performance and consistent cooking heat. What it does:

• Covers the burner head and helps direct gas flow for a stable, even flame
• Helps maintain proper flame pattern to avoid hot spots and uneven cooking
• Can resolve weak, flickering, or irregular flames when the cap is warped or missing
• Protects the burner head from spills and debris that can block ports

What's included: One burner inner cap as shown Install notes:

• Turn off the range and allow the burner to cool completely before servicing
• Remove the burner grate and lift off the old cap; seat the new cap flat onto the burner head
• Do not force or pry the cap into place—align it and let it sit naturally on the burner surface
• After installation, check burner ignition and flame pattern; if you smell gas or see unsafe flames, stop use.
