Best Seller
Manufacturer Part

Whirlpool W10836409 Surface Burner Head OEM Part

Manufacturer's Part Number: W10836409
Genuine Whirlpool part
Appliance Compatibility Tool
$78.95
IN STOCK - SHIPS TODAY
Compare At:
$93.95
You Save:
$15.00

Secure and trusted checkout with

IN STOCK Less than 100 left
Ships Today Guaranteed

Order now and we'll ship it out Today

Over 94% of our orders are delivered in 2 days or less

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10836409 replaces AP5988679, W10398571, W10617289, 4378109, PS11727871, W10617678, W10730779, W10808715, W10809077.

Description

This surface burner head distributes gas to create an even, consistent flame on your range's cooktop. Replacing a damaged or clogged head restores reliable ignition and proper heat on the affected burner. What it does:
  • Directs the gas/air mix through flame ports for an even flame pattern
  • Works with the spark igniter and burner cap to light the burner
  • Helps ensure steady simmering and full burner output
  • Worn, corroded, or clogged heads can cause weak, uneven, yellow, or no flame
What's included:
  • 1 surface burner head
Install notes:
  • Disconnect power and shut off gas; allow the cooktop to cool
  • Remove grate and burner cap, then lift off or unfasten the old head
  • Position the new head over the orifice and igniter; secure with the original hardware
  • Reinstall the cap and grate, restore gas/power, and verify ignition and flame pattern

Frequently Bought Together

This item

Product photo

Whirlpool W10836409 Surface Burner Head OEM Part

Total price:

$130.56

Do-It-Yourself Stories from Customers like You

Total Satisfaction Rating
5.0
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Do-It-Yourself Rating
Very Easy
Less than 15 minutes

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Whirlpool W10836409 Surface Burner Head OEM Part

Part Number:
OEM17966046
Manufacturer's Part Number:
W10836409
