Whirlpool W10832694 Burner Cap OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10832694 replaces AP5988633, 4363154, PS11727796, W10597133.

Description

This burner cap sits on top of the gas burner head to shape the flame and shield it from spills. Replacing a damaged or missing cap restores proper flame pattern, reliable ignition, and even heating.

• Shapes and disperses the burner flame for even cooking and proper simmering
• Shields the burner head/orifices from spills, grease, and debris
• Must sit level and centered for consistent ignition and flame quality
• Replace if cracked, chipped, warped, missing, or if flames are uneven or yellow

What's included: Includes 1 burner cap. Install notes:

• Allow the appliance to cool completely. Turn off gas supply and power before servicing.
• Lift off the old cap; clean and dry the burner head so the new cap seats properly.
• Center the new cap on the matching burner; it should sit flat with no rocking or gaps.
• Light the burner to verify an even, blue flame; realign the cap if ignition is delayed or the flame is uneven.
