Whirlpool W11205294 Burner Cap (Surface Burner), 1 Each OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11205294 replaces AP6327354, 4784568, PS12349216, W11169224.

Description

This replacement burner cap sits on a gas range surface burner to protect the burner head and help direct the flame for more even heating. Use it to replace a cracked, chipped, or missing cap and restore stable burner performance. What it does:

• Covers the burner head to help shape and stabilize the gas flame for consistent cooking.
• Promotes even heat distribution across cookware by centering the flame.
• Keeps spills and food debris off burner ports for easier cleaning and more reliable ignition.
• Replace when cap is cracked, chipped, displaced, or causing uneven or yellowish/erratic flames.

What's included: One burner cap. Install notes:

• Make sure the range is turned off and fully cooled before handling burners.
• Remove the grate, lift the old cap straight off, and seat the new cap flat and centered on the burner head — no tools typically required.
• If the cap does not sit flush, clean the burner head of debris before reinstalling; do not force the cap.
