Whirlpool WPW10597129 Surface Burner Cap OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10597129 replaces AP6023309, W10597129, 4448729, PS11756651.

Description

This surface burner cap sits on top of a gas burner head to shape the flame and shield the burner from spills. Replace a missing, chipped, or warped cap to restore even flame, clean combustion, and reliable ignition.

• Shapes and stabilizes the flame for consistent cooking heat
• Protects the burner head from spills and debris
• Supports proper ignition when correctly seated
• Typical symptoms: uneven/yellow flames, delayed ignition, clicking without lighting, visible chipping or warping

What's included: 1 surface burner cap Install notes:

• Disconnect power and shut off gas; allow the cooktop/range to cool completely
• Lift off the old cap and clean the burner head and seating surface
• Place the correct cap for that burner size; align and seat it flat and centered
• Restore gas and power; test ignition and flame, and reseat if the flame is uneven

Fit note: Burner caps are size- and position-specific; match the cap to the original for the correct burner location.
