Whirlpool W10480130 Electronic Control Board (Console), 1 OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10480130 replaces AP5629537, 2312657, PS3653302, W10405817, W10445303.

Description

This electronic control board is the main console controller that manages a range of dryer functions and touchpad/LED commands, restoring normal user interface and cycle control when the original board has failed. What it does

• Controls cycle selection, timing, and display behavior for the appliance.
• Receives inputs from the touchpad/control panel and sends commands to motors, heaters, and sensors.
• Commonly replaced when the display is blank, buttons don't respond, cycles won't start, or error codes indicate control faults.
• Works as the central communication hub between sensors and mechanical components.

What's included

• One electronic control board.

Install notes

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Take photos of wire locations or label harnesses before disconnecting to ensure correct reassembly.
• Handle the board carefully to avoid static damage; avoid touching components and connectors.
• If wiring, connectors, or the touchpad are damaged, inspect and replace those parts separately as needed.
