Whirlpool W10480131 Electronic Control Board (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10480131 replaces AP5629839, 2312658, PS3653303, W10405818, W10445326.

Description

This electronic control board assembly manages the appliance's user interface and timed cycles so your unit runs the selected programs correctly. Replacing a faulty board restores reliable control and cycle operation when other parts are working. What it does:

• Receives inputs from the console and issues commands to motors, valves, heaters, and timers
• Regulates cycle timing and mode selection for accurate operation
• Common symptoms: unresponsive controls, failure to start cycles, incorrect cycle behavior, or error codes related to control faults
• Works only when the rest of the appliance (door switches, fuses, wiring) is functioning properly

What's included: One electronic control board assembly. Install notes:

• Disconnect power before starting work to avoid shock or damage
• Handle the board by edges and avoid static discharge; use grounding measures if available
• Verify connectors and harnesses are fully seated; confirm part matches the original before installation
