Whirlpool W10480169 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10480169 replaces AP5645949, 2684289, PS4704631, W10438102, W10445381.

Description

This electronic control board manages the cycle commands and user interface for your appliance, restoring responsive controls and reliable cycle selection. Designed to replace a failed or unresponsive console control for normal operation. What it does:

• Receives input from buttons and knob controls and sends signals to start, stop, and change cycles.
• Controls timed events and communicates with other modules to regulate functions like motor, heater, and valves.
• Helps clear intermittent faults caused by a damaged or shorted control board when confirmed by diagnostics.

What's included:

• One electronic control board (main console)

Install notes:

• Disconnect power to the appliance before beginning work to avoid shock or damage.
• Handle the board by its edges and avoid touching components; observe electrostatic discharge (ESD) precautions.
• Reconnect all wiring harnesses exactly as removed; verify secure connections before restoring power.
• Test appliance through a full cycle after installation to confirm proper operation.
