Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W10480320 replaces AP5644061, 2312668, PS4082836, W10423474, W10445354.
Description
This electronic control board is the appliance's main control module that manages cycles, user inputs, and timed operations so your appliance responds correctly to selected settings and runs intended programs. What it does:
- Interprets console inputs and runs the appliance's control logic and timed sequences
- Sends power and signals to motors, valves, heaters, and displays as commanded
- Common symptom fixes: unresponsive controls, display errors, no cycle start, or intermittent operation
- Replaces a failed or damaged control board to restore normal electronic control
What's included: One electronic control board (single unit) Install notes:
- Disconnect power at the breaker before starting any repair to avoid shock
- Handle board carefully; protect against static discharge and avoid touching components
- Follow for access, connector order, and mounting details
- Verify error codes and diagnostics to confirm the control board is the failed component before replacing
