Whirlpool W10484688 Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10484688 replaces AP5620243, 2312725, PS3651448.

Description

This is an electronic control board that is made for use with washing machines. It is an internal component that ensures the washing machine operates correctly. The electronic control board monitors sensors throughout the appliance to ensure wash and spin speeds, drain and fill time, and water temperature is regulated. It also carries out user commands for washing machine cycle preferences.If the electronic control board has failed or gone bad, it can cause several problems. The washer may not spin, drain, fill, or even start a cycle. If it's determined that the problem is related to the electronic control board, it will need to be replaced. Unplug the washer and check the wire connections on the electronic control board. If they are fine, the electronic control board needs to be replaced. A putty knife, nut driver, and flat screwdriver will be needed. Remove the knob, open the console, and disassemble the main control board to remove it. Install the new replacement part and reassemble.This authentic OEM part is made for washing machines manufactured by Whirlpool. The component comes directly sourced from the manufacturer, and it is sold as a single part.
