Whirlpool W10484689 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10484689 replaces AP5629543, 2312726, PS3653329.

Description

This electronic control board is the refrigerator's main control module that manages user commands, cycles, and system timing to restore normal operation. It replaces a failed or unresponsive control board to get electronic functions working again. What it does:

• Receives button and sensor signals and controls compressor, fans, defrost, and other timed functions
• Can resolve symptoms like no display or lights, unresponsive controls, or erratic cycling
• Helps correct intermittent or failed electronic sequencing caused by a faulty control board
• Works with factory wiring harness and mounting locations to restore original functionality

What's included: One electronic control board Install notes:

• Disconnect power to the appliance before starting any repair
• Handle the board by its edges; avoid touching components and use anti-static precautions
• Verify connector seating and mounting orientation before restoring power
