Whirlpool W10520038 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10520038 replaces AP5645612, 2684810, PS4704838.

Description

This electronic control board is the appliance's main control module. It manages power distribution, cycle timing, and user inputs so functions run correctly, helping resolve issues caused by a failed or unresponsive control board. What it does:

• Controls and coordinates operations, including timing, power routing, and safety interlocks
• Interprets keypad/knob inputs and sensor feedback to start, stop, and adjust cycles
• Drives relays to power motors, valves, heaters, and other loads
• Displays status or fault codes when a failure is detected
• Common symptoms: unresponsive controls, blank/flickering display, won't start or stops mid-cycle, recurring control-related error codes

What's included:

• 1 electronic control board

Install notes:

• Disconnect power at the breaker or unplug before servicing; verify no voltage present
• Use ESD protection; handle the board by its edges to avoid static damage
• Photograph/label all connectors and transfer wires one at a time to the new board
• Secure the board, then follow the model's tech sheet for any required setup/diagnostics and test operation

Also known as: CNTRL-ELEC, main control board, control module
