Whirlpool W10636054 Washing Machine Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10636054 replaces AP5804501, 3023641, PS8768904.

Description

This is a Whirlpool control board for washing machines. When users select a wash cycle, adjust the water level, or change the water temperature, this component ensures that command is carried out. However, over time, internal faults can occur that will require replacing the board. Signs that the board is failing or has failed include an inability to control the washer and cycles skipping or failing.Replacing the washing machine control board is relatively simple. First, unplug the washer. Next, pull it away from the wall. Remove the screws that secure the rear access panel (top) in place and remove the panel. The control board is held in place with a bolt and should be visible. Disconnect the wiring harness, remove the screw, and then remove the board. Reassemble the entire thing by following these steps in reverse.This genuine OEM part is sold individually and designed to fit Maytag, Whirlpool, and Admiral brand washing machines.
