Whirlpool W10741603 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10741603 replaces AP5954414, W10496288, 3452727, PS10062747, W10668452.

Description

This electronic control board is the appliance's main control. It coordinates cycle timing and powers key components, helping restore normal operation when the original board fails or causes unresponsive controls, stalled cycles, or error codes.

• Manages inputs from sensors and the user interface to execute programmed cycles
• Distributes power to motors, valves, heaters, fans, and other loads as required
• Stores and runs cycle logic and built-in safety interlocks
• Common symptoms of a failing board: unit won't start, unresponsive controls, cycle won't advance, error codes or blinking lights, intermittent operation

What's included: 1 electronic control board Installation notes:

• Disconnect power at the breaker or unplug the appliance before servicing
• Use ESD protection and handle the board by the edges to avoid static damage
• Photograph/label wiring and transfer connectors one at a time to matching terminals
• Follow the tech sheet/service manual after installation; ensure covers/gaskets are reinstalled to protect the board
