Whirlpool W10802463 Electronic Control Board (Main Control Board) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10802463 replaces AP5983662, 4283091, PS11722916, W10771991.

Description

This electronic control board is the appliance's main controller, managing cycle selection, timing and user interface functions so your appliance runs the selected options correctly. It restores electronic control when the original board fails. What it does:

• Regulates cycle operations, timing and electronic commands for the appliance
• Interprets user inputs and powers the display and touchpad/knobs
• Helps control motors, valves and heaters through relay outputs
• Common symptoms: blank or unresponsive display, failure to start, error codes or intermittent operation

What's included:

• One electronic control board

Install notes:

• Disconnect power before beginning service and follow all safety precautions
• Access typically requires removing the control or console panel; keep screws and fasteners organized
• Handle the board carefully to avoid ESD damage; avoid touching contacts
• Verify wiring harness connectors seat fully and inspect for heat or water damage before installing
