Whirlpool W10804117 Electronic Control Board OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10804117 replaces AP5985750, 4283130, PS11722933, W10650775, W10671760, W10711372, W10756239.

Description

This Electronic Control Board is the central circuit module that governs your appliance's cycles and features. Replacing a failed board restores proper operation, responsive controls, and reliable performance when the original no longer communicates with key components.

• Coordinates timing and sequencing for cycles and options
• Interprets sensor inputs and sends power to motors, heaters, valves, pumps, or fans
• Resolves symptoms such as blank or unresponsive controls, won't start/finish, intermittent resets, error codes, or erratic operation
• Commonly replaced when the old board shows burn marks, clicking relays, or repeated lockups

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker or unplug before servicing; verify no voltage present
• Use ESD precautions; handle the board by the edges
• Photograph wiring and move connectors one at a time; transfer any jumpers or mounting hardware from the original board
• After reassembly, restore power and run a test/diagnostic per the service manual to verify operation
