Whirlpool W10814129 Electronic Control Board (Console) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10814129 replaces AP5985772, W10753617.

Description

This electronic control board replaces a failed console controller to restore oven control functions and front-panel responsiveness. It manages touchpad inputs, display readouts, and timed cooking operations so your range responds correctly. What it does:

• Receives inputs from the cooktop/oven control panel and sends commands to heating elements and relays
• Drives the front display and status indicators so settings and timers show correctly
• Can resolve symptoms like unresponsive buttons, blank or garbled display, or improper heating cycles
• Re-establishes communication between user interface and oven power/control systems

What's included:

• One electronic control board

Install notes:

• Disconnect power to the appliance before starting — risk of shock or damage
• Compare the new board to the old one for matching connectors and mounting points before installing
• Handle the board by its edges and avoid touching components to prevent ESD damage
• If you find additional issues (damaged wiring, burned connectors), address those before reconnecting power
