Whirlpool W10847487 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10847487 replaces AP6030393, 4459164, PS11765135, W10565997, W10668850, WPW10565997.

Description

• Interprets user inputs and runs cycle logic for timed and sensor-driven operations
• Communicates with touchpads, LEDs/displays and connected sensors or actuators
• Starts and stops motors, valves, heaters or other components based on programmed logic
• Can cause symptoms like no power to controls, unresponsive buttons, error codes, or interrupted/failed cycles when faulty

• One electronic control board

• Disconnect power to the appliance before starting work to avoid shock or damage
• Handle the board by its edges and avoid touching components; use anti-static precautions if available
• Some installations require removal of panels, bezels, or the control console; save and reuse any mounting hardware
• If the original board uses plug-in harnesses or sensors, ensure connectors are seated fully; transfer any sensors or brackets
