Whirlpool W10854221 Electronic Control Board (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10854221 replaces AP6004682, 4454789, PS11737961, W10746418, W10782663, W10791027, W10833927, W10833930, W10851343.

Description

This electronic control board is the appliance's primary control module, coordinating power and timing for critical functions. Replacing a failed board can resolve no-power, stalled-cycle, or recurring error issues to restore reliable operation.

• Directs motors, valves, heaters, fans, and lights based on sensor feedback and user selections
• Manages cycle timing and safety interlocks to run the programmed operation
• Interprets inputs from the user interface and monitors system status
• Stores diagnostics and triggers fault protection when problems are detected
• Common failure symptoms: won't start or power up, unresponsive/intermittent controls, cycles that won't advance, or persistent error codes

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker before servicing
• Use ESD precautions; handle the board by the edges only
• Photograph wiring; move connectors one at a time; transfer any jumpers or configuration plugs from the original board
• After installation, run the unit's diagnostic/service test per the tech sheet to verify operation
